NSYTRV26T

Schneider Electric NSYTRV26T: Linergy TR is terminal block for Linergy. It belongs to linergy passthrough terminal block with 2.5 mm² nominal cross section. The rated operational voltage is 500V conforming to EN/IEC 60947-7-1. The rated current is 20A conforming to EN/IEC 60947-7-1. It has grey surface treatment. Mounting by clip-on and sideways connection by three-level 1x1 screw terminals. It could be connection and disconnection by screwdriver. It is compatible with spacial enclosures for Prisma G, Prisma P, Pragma, Prisma PH, Prisma Pack, Spacial, Kaedra, TeSys. Sold in lots of 50 units. Ambient air temperature for operation is from -40 to 130 °C conforming to IEC 60216-1 and VDE 0304-T21. Multi standards certified (CSA, cURus, EAC). It is compliant with Green Premium (RoHS/REACH).

Manufacturer

Schneider Electric

Part number

NSYTRV26T

Product family

TeSys

Category

Contactors & Motor Control

Technical details

Range: TeSys; Voltage: 500V; Current: 20A; Published sizes: 2,5MM, 2.5 mm; Temperature: -40 to 130 °C; Colour: GREY, Green; Official designation: SCREW TERMINAL, 3 LEVELS, 6 POINTS, 2,5MM², GREY
