NSYTRV162SF

Schneider Electric NSYTRV162SF: Linergy TR is terminal block for Linergy. It belongs to linergy fixed carrier terminal block with 16 mm² nominal cross section. The rated operational voltage is 300V conforming to CSA/cURus and 500V conforming to EN/IEC 60947-7-1. The rated current is 10A conforming to EN/IEC 60947-7-1 and 20A conforming to CSA and cURus. It has black surface treatment. Mounting by clip-on and sideways connection by single-level 1x1 screw terminals. It could be connection and disconnection by screwdriver. It is compatible with spacial enclosures for Prisma G, Prisma P, Pragma, Prisma PH, Prisma Pack, Spacial, Kaedra, TeSys. Sold in lots of 50 units. Ambient air temperature for operation is from -40 to 130 °C conforming to IEC 60216-1 and VDE 0304-T21. Multi standards certified (CSA, cURus, DNV, LR, EAC). It is compliant with Green Premium (RoHS/REACH).

Manufacturer

Schneider Electric

Part number

NSYTRV162SF

Product family

TeSys

Category

Contactors & Motor Control

Technical details

Range: TeSys; Voltage: 300V, 500V; Current: 10A, 20A; Dimensions: 5X20MM; Published sizes: 16 mm; Temperature: -40 to 130 °C; Colour: black, Green; Official designation: SCREW TERMINAL, FUSED, SCREW CAP, FOR 5X20MM CARTRIDGE FUSE, 2PTS, 10
