6080742

SICK 6080742 / IDM141-411S is a mobile handheld scanner in the IDM family. Readable code structures: 1D codes, Stacked; Reading distance: 20 mm... 850 mm; Application: Standard application; Scanner design: Wireless variant; Note: Additional accessories may be necessary for some communication interfaces (details available online); Communication interface: Ethernet, PROFINET, EtherCAT®, Serial, PROFIBUS DP, USB, Bluetooth; Ambient operating temperature: –10 °C... +50 °C; Code resolution: ≥ 0.076 mm.

Manufacturer

Sick

Part number

6080742

Product family

IDM

Category

Mobile handheld scanners

Technical details

Code resolution: ≥ 0.076 mm; Supply voltage: 3.7 V DC... 5 V; Dimensions (L x W x H): 97.8 mm x 70.5 mm x 156.2 mm; Enclosure rating: IP52; Ambient operating temperature: –10 °C... +50 °C; Weight: 230 g, incl. rechargeable battery; Application: Standard application; Version: Standard Range; Scanner design: Wireless variant; Light source: LED, Visible, Red, 630 nm; Reading distance: 20 mm... 850 mm; Scanning frequency: ≤ 500 Hz; Current consumption: ≤ 180 mA; ≤ 80 mA; Housing color: Black/gray

Weight

0.23 kg

Dimensions

97.8 x 70.5 x 156.2
