6074385

SICK 6074385 / OD2000-7002T15 is a laser distance sensor in the OD2000 family. Communication interface: IO-Link; Digital output: 2 x PNP/NPN, selectable; Type of analog output: Current output / voltage output; Measuring range: 200 mm... 1,200 mm; Linearity: ± 1,000 µm, ± 3,000 µm; Laser class: 2; Typ. light spot size (distance): Ø 1 mm (700 mm); Housing material: Plastic; Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm.

Manufacturer

Sick

Part number

6074385

Product family

OD2000

Category

Laser distance sensors

Technical details

Resolution: 16 bit; Supply voltage UB: DC 18 V... 24 V, ± 10%, including residual ripple; Repeatability: 100 µm; Response time: ≥ 0.533 ms; Dimensions (W x H x D): 27 mm x 60 mm x 50 mm; Connection type: Cable with male connector, M12, 5-pin, A-coded, 30 cm; Enclosure rating: IP67; Housing material: Plastic (PBT); Weight: 90 g; Measuring range: 200 mm... 1,200 mm; Linearity: ± 1,000 µm, 200 mm... 700 mm; ± 3,000 µm, 700 mm... 1,200 mm; Measuring frequency: ≤ 7.5 kHz; Output time: ≥ 0.1333 ms; Emitted beam: Light source Laser, red

Weight

0.09 kg

Dimensions

27 x 60 x 50
