CP1E-NA20DT-D

Omron CP1E-NA20DT-D is a PLC. PLC, 24 VDC supply, 12 x 24 VDC inputs, 8 x NPN outputs 0.3 A, 2 x analog inputs, 1 x analog output, resolution 1/6000, 8K steps program + 8K words data memory, RS-232C port.

Manufacturer

Omron

Part number

CP1E-NA20DT-D

Product family

CP1E

Category

PLCs & Controllers

Technical details

Supply voltage type: DC; Number of digital inputs: 12; Input type: PNP/NPN; Number of digital outputs: 8; Output type: NPN; Program capacity: 8 K steps; Data memory capacity: 8 K words; Logic execution time: 1.19 µs; Communication port(s): Serial RS-232C, USB; Number of Ethernet ports: 0; Number of USB ports: 1; Number of RS-232 ports: 1; Number of RS-485 ports: 0; Communication option(s): Ethernet TCP/IP, Serial RS-232C, Serial RS-422, Serial RS-485; Max. encoder input frequency: 100 kHz; Max. number of PTP axes: 2; Max. pulse output frequency: 100 kHz; Function Block programming: FALSE; Battery-free memory backup: FALSE; Real-time clock: TRUE; Analogue option boards: TRUE; Max. number of analogue I/O channels: 31; Max. number of local I/O points: 140; Max. number of expansion units: 3; Built-in auxiliary 24 VDC output: 0 mA; Operating temperature range: 0-55 °C; Product Height (unpacked): 90 mm; Product Width (unpacked): 130 mm; Product Depth (unpacked): 85 mm; Product Weight (unpacked): 550 g

Weight

0.55 kg

Dimensions

90 × 130 × 85 (H × W × D)
