5324173

SICK 5324173 / LL3-TX01 is a fiber-optic sensor in the Fiber-optic cables family. Functional principle: Through-beam system; Fiber-optic head design: Threaded sleeve; Fiber length: 20,000 mm; Thread diameter (housing): M12; Fiber material: Plastic; Jacket material: Plastic; Fiber head material: Stainless steel; Included with delivery: Mounting, 4 x M12 hexagon nut, FC fiber cutter (5304141), protective cladding for fiber head.

Manufacturer

Sick

Part number

5324173

Product family

Fiber-optic cables

Category

Fiber-optic sensors

Technical details

Sensing range max.: 38,000 mm (Sensing range of WLL80 at 8 ms); Ambient operating temperature: –40 °C... +60 °C; Weight: 23 g; Device type: Fiber-optic cables; Functional principle: Through-beam system, consisting of a sender and a receiver; Fiber-optic head design: Threaded sleeve; Application: Standard; Compatible fiber-optic amplifiers: GLL70, WLL80, WLL180, GLL170(T), WLL24 Ex; Minimal object diameter: 0.5 mm; Optical fiber head: Angle of dispersion 14°; Integrated lens: Yes; Compatibility tip adapters: No; Optical fiber: Compatibility with infrared light No; Optical fiber cable can be shortened: ✔

Weight

0.023 kg
