2073504

SICK 2073504 / LL3-LM38751 is a fiber-optic sensor in the Fiber-optic cables family. Functional principle: Through-beam system; Fiber-optic head design: Flat type, 90° deflection; Fiber length: 750 mm; Fiber material: Glass; Jacket material: Plastic; Fiber head material: Aluminum.

Manufacturer

Sick

Part number

2073504

Product family

Fiber-optic cables

Category

Fiber-optic sensors

Technical details

Sensing range max.: Depending on the fiber optic amplifier used; Ambient operating temperature: –10 °C... +60 °C; Weight: 83 g; Device type: Fiber-optic cables; Functional principle: Through-beam system, consisting of a sender and a receiver; Fiber-optic head design: Flat type, 90° deflection; Application: Standard; Compatible fiber-optic amplifiers: GLL70, WLL80, WLL180, GLL170(T); Minimal object diameter: 0.5 mm; Optical fiber head: Angle of dispersion 54°; Integrated lens: Yes; Compatibility tip adapters: No; Optical fiber: Compatibility with infrared light Yes; Adapter end sleeves required: No

Weight

0.083 kg
