170ANR12090

Schneider Electric 170ANR12090 is a distributed analog/discrete I/O Modicon Momentum. This I/O module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This distributed analog, discrete I/O base module offers 8 discrete outputs, 8 discrete inputs, 6 analog inputs and 4 analog outputs.

Manufacturer

Schneider Electric

Part number

170ANR12090

Product family

Modicon Momentum

Category

PLC and Automation Components

Technical details

This distributed analog, discrete I/O base module offers 8 discrete outputs, 8 discrete inputs, 6 analog inputs and 4 analog outputs; It is a module with analog input/output voltage ranges from 0V to 10V and discrete input voltage of 24V DC and discrete output voltage from 10V to 30V; There is an isolation between analog I/O and operating voltage, operating voltage and I/O from the ground at 500V; It is furnished with 2 removable terminal blocks for electrical connection; It features 4 LEDs for channel status signaling; Its dimensions are 141.5mm (width) x 47.5mm (depth) x 125mm (height); It weighs 0.24kg

Weight

0.24 kg

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
