170ADO53050

Schneider Electric 170ADO53050 is a discrete output module Modicon Momentum - 8 O solid state. This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base AC module offers 2 groups of 16 outputs, 32 discrete outputs with triac type.

Manufacturer

Schneider Electric

Part number

170ADO53050

Product family

Modicon Momentum

Category

I/O Modules

Technical details

This discrete output base AC module offers 2 groups of 16 outputs, 32 discrete outputs with triac type; It offers discrete output voltage of 120V AC; There is an isolation between the channels and the bus at 1780V AC; It features 16 LEDs for channel status signaling; Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height), and it weighs approximately 0.32 kg; It is suitable for wall mount; System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems

Weight

0.32 kg
