170ADI35000

Schneider Electric 170ADI35000 is a discrete input module Modicon Momentum - 32 Input 24 V DC. This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base DC module offers 2 groups of 16 inputs, conforming to IEC 1131-2 type 1 with positive discrete input logic.

Manufacturer

Schneider Electric

Part number

170ADI35000

Product family

Modicon Momentum

Category

I/O Modules

Technical details

It is a module with discrete input voltage of 24V DC; There is an isolation between channels and ground at 500V AC; It features 32 LEDs for channel status signaling; Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height); It weighs 0.2kg; It is suitable for wall mount; System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems

Weight

0.2 kg

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
