170ADO34000

Schneider Electric 170ADO34000 is a discrete output module Modicon Momentum - 16 O solid state. This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base DC module offers 2 groups of 8 outputs, 16 discrete outputs with solid state switch type.

Manufacturer

Schneider Electric

Part number

170ADO34000

Product family

Modicon Momentum

Category

I/O Modules

Technical details

This discrete output base DC module offers 2 groups of 8 outputs, 16 discrete outputs with solid state switch type; It offers discrete output voltage of 24V DC; There is an isolation between channels and bus at 500V AC; It features 16 LEDs for channel status signaling; Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height); It weighs 0.21kg; It is suitable for wall mount

Weight

0.21 kg
