1133391

SICK 1133391 / BTF13-A1ZM10S01 is an archive in the HighLine family. Wire draw encoders; Measuring range: 0 m... 10 m; Communication interface: SSI; Supply voltage: 4.5 V DC... 32 V DC; Connection type: Special version; Mounted encoder: AHM36 SSI, AHM36A-S3PZ000S10, 1129703; Mounted mechanic: MRA-F130-110D2, 6028627; Programmable/configurable: yes; Besonderheit: BTF13-A1AM1020 successor:, Encoder AHM36A-S3PZ000S10, 1129703 pre-assembled.

Manufacturer

Sick

Part number

1133391

Product family

HighLine

Category

Archive

Technical details

Measurement range: 0 m... 10 m; Resolution (wire draw + encoder): 0.05 mm; Supply voltage: 4.5 V DC... 32 V DC; Communication interface: SSI; Repeatability: ≤ 1.5 mm; Connection type: Special version; Connection type Detail: Cable, 8-wire, with male connector, M23, 12-pin, universal, 0.1 m; Enclosure rating: IP64, mounted mechanic; IP66, Encoder (IEC 60529); IP67, Encoder (IEC 60529); Housing material, wire draw mechanism: Aluminum (anodised), plastic; Weight: 4 kg; Special device: ✔; Specialty: BTF13-A1AM1020 successor:; Encoder AHM36A-S3PZ000S10, 1129703 pre-assembled; Standard reference device: BTF13-A1AM1020, 1034301; MTTFD (mean time to dangerous failure): 230 years (EN ISO 13849-1)

Weight

4 kg
