1126340

SICK 1126340 / WTB12L-24161A20A00 is a photoelectric sensor in the W12 family. Sensing range min. / max.: 80 mm / 1,200 mm; Functional principle: Photoelectric proximity sensor; Functional principle detail: Background suppression; Switching output: Push-pull: PNP/NPN; Switching mode: Light/dark switching; Connection type: Male connector M12, 4-pin; Light source: Laser; Type of light: Visible red light; Laser class: 1; Housing material: Zinc diecast; Adjustment: Teach-in button, Potentiometer, Teach-Turn adjustment, IO-Link; Communication interface: IO-Link V1.1; Smart Sensor: Enhanced Sensing, efficient communication, diagnosis, Smart Task; Smart Task name: Base logics; Housing: Rectangular; Focus position: 800 mm.

Manufacturer

Sick

Part number

1126340

Product family

W12

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range: Sensing range min. 80 mm; Sensing range max.: 1,200 mm; Minimum distance between set sensing range and background (black 6% / white 90%): 6 mm, at a distance of 650 mm; Recommended sensing range for the best performance: 90 mm... 500 mm; Supply voltage UB: 10 V DC... 30 V DC; IO-Link communication C Function of pin 4/black (BK) – detail: The pin 4 function of the sensor can be configured; Overcurrent protected Short-circuit protected Response time: ≤ 15 ms; Repeatability (response time): 5 ms; Response time: SIO logic: 550 µs; IOL: 600 µs; Repeatability: SIO Logic: 200 µs; IOL: 250 µs; Dimensions (W x H x D): 15.6 mm x 49.5 mm x 43.1 mm; Enclosure rating: IP66 (EN 60529); IP67 (EN 60529); IP69 (EN 60529); Ambient operating temperature: –20 °C... +55 °C

Weight

0.077 kg

Dimensions

15.6 x 49.5 x 43.1
