1018252

SICK 1018252 / WL12L-2B530 is a photoelectric sensor in the W12 family. W12-2 Laser; Sensing range max.: 0 m... 18 m; Functional principle: Photoelectric retro-reflective sensor; Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics); Switching output: PNP, NPN; Switching mode: Light switching, Dark switching; Connection type: Plug, M12, 5-pin; Light source: Laser; Type of light: Visible red light; Laser class: 2; Adjustment: Potentiometer; Special features: Focusable from 300 mm to infinite; Housing: Rectangular; Included with delivery: 2 x clamps BEF-KH-W12, incl. screws.

Manufacturer

Sick

Part number

1018252

Product family

W12

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0 m... 18 m; Supply voltage UB: 10 V DC... 30 V DC; Response time: ≤ 200 µs; Dimensions (W x H x D): 15 mm x 49 mm x 41.5 mm; Enclosure rating: IP67; IP69K; Ambient operating temperature: –10 °C... +50 °C; Weight: 130 g; Functional principle: Photoelectric retro-reflective sensor; Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics); Polarisation filter: Yes; Emitted beam: Light source Laser; Light spot size (distance): Ø 0.8 mm (300 mm); Key laser figures: Normative reference EN 60825-1:2014, IEC 60825-1:2007

Weight

0.13 kg

Dimensions

15 x 49 x 41.5

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
