1096990

SICK 1096990 / ZLD18-APZAG8 is a photoelectric sensor in the Z18 Simple Sense family. Communication interface: -; Mounting system type: M18, head/side (24.1 … 25.4 mm); Sensor/ detection principle: Photoelectric retro-reflective sensor, With minimum distance to reflector (dual lens system); Sensing range: 5 m; Light source, light type: LED, visible red light; Switching output Q1: PNP, Light switching; Switching output Q2: Not connected; Connection type: Cable with connector RJ11, 6-pin, 2,000 mm.

Manufacturer

Sick

Part number

1096990

Product family

Z18 Simple Sense

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0 m... 5 m; Sensing range: 0 m... 4.2 m; Supply voltage UB: 10 V DC... 30 V DC; Switching output: PNP; Switching output detail: Switching output Q1 PNP, Light switching; Switching output Q2: Not connected; Response time: ≤ 500 µs; Dimensions (W x H x D): 13.6 mm x 34.8 mm x 23 mm; Connection type: Cable with connector RJ11, 6-pin, 2,000 mm; Connection type Detail: Cable material Plastic; Enclosure rating: IP67; Housing material: Plastic, ABS; Ambient operating temperature: –40 °C... +55 °C

Weight

0.00363 kg

Dimensions

13.6 x 34.8 x 23
