1062507

SICK 1062507 / MPS-064TLTQ0 is a cylinder sensor in the MPS-T family. Measuring range: 64 mm; Connection type: Cable with plug, M12, 4-pin, 0.3 m; Switching output / output function / enclosure rating: IO-Link, IP67; Electrical wiring: DC 4-wire; Smart Sensor: Enhanced Sensing, efficient communication, diagnosis; Communication interface: IO-Link.

Manufacturer

Sick

Part number

1062507

Product family

MPS-T

Category

Cylinder sensors

Technical details

Resolution, typ.: 0.03 % FSR (max. ≥ 0.05 mm); Supply voltage: 15 V DC... 30 V DC; Communication interface: IO-Link V1.1; Communication Interface detail: COM2; Repeat accuracy, typ.: 0.06 % FSR (≥ 0.1 mm); Connection type: Cable with plug, M12, 4-pin, 0.3 m; Connection type Detail: Deep-freeze property Do not bend below 0 °C; Enclosure rating: IP67; Ambient operating temperature: –20 °C... +70 °C; Cylinder type: T-slot; Cylinder types with adapter: Round body cylinder; Profile cylinders and tie-rod cylinders; Dovetail groove cylinder; Measuring range: 64 mm; Housing length: 77 mm; Output function: IO-Link

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
