1045672

SICK 1045672 / MPS-128TSTP0 is a cylinder sensor in the MPS-T family. Measuring range: 128 mm; Connection type: Cable with M8 male connector, 4-pin, 0.3 m; Switching output / output function / enclosure rating: Analog, IP67; Electrical wiring: DC 4-wire; Communication interface: -.

Manufacturer

Sick

Part number

1045672

Product family

MPS-T

Category

Cylinder sensors

Technical details

Resolution, typ.: 0.03 % FSR (max. ≥ 0.05 mm); Supply voltage: 15 V DC... 30 V DC; Repeat accuracy, typ.: 0.06 % FSR (≥ 0.1 mm); Connection type: Cable with M8 male connector, 4-pin, 0.3 m; Connection type Detail: Deep-freeze property Do not bend below 0 °C; Enclosure rating: IP67; Ambient operating temperature: –20 °C... +70 °C; Cylinder type: T-slot; Cylinder types with adapter: Round body cylinder; Profile cylinders and tie-rod cylinders; Dovetail groove cylinder; Measuring range: 128 mm; Housing length: 141 mm; Output function: Analog; Electrical wiring: DC 4-wire; Analog output (voltage): 0 V... 10 V
