1019445

SICK 1019445 / KT3G-N1116 is an archive in the KT3 family. Contrast sensors; Light source: LED; Sensing distance: 12.5 mm; Switching output: NPN; Light spot size: 1.5 mm x 3.5 mm; Light spot direction: Vertical; Connection type Detail: Male connector M12, 4-pin; Adjustment: Teach-in button; Teach-in mode: Static 2-point teach-in; Housing material: Plastic.

Manufacturer

Sick

Part number

1019445

Product family

KT3

Category

Archive

Technical details

Supply voltage: 12 V DC... 24 V DC; Switching output: NPN; Switching output (voltage): NPN: HIGH = approx. UV / LOW ≤ 2 V; Response time: 50 µs; Dimensions (W x H x D): 12 mm x 40 mm x 22 mm; Connection type: Male connector M12, 4-pin; Enclosure rating: IP67; Housing material: ABS; Ambient operating temperature: –10 °C... +55 °C; Weight: 11 g; Housing design: Middle; Light source: LED, visible green light; Light spot size: 1.5 mm x 3.5 mm; Light spot direction: Vertical

Weight

0.011 kg

Dimensions

12 x 40 x 22

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
