TCSEFEC23FCF21

Schneider Electric TCSEFEC23FCF21: This product is part of the Modicon Networking range, an offer of Industrial Firewall/Router. This device comes with Ethernet TCP/IP protocol. It comes with 1 copper cable transmission port and 1 port for multi-mode fiber optic. It provides secure connectivity for multiple Ethernet device, network management, enhanced cyber security and more advanced switching features. This product works at a power consumption of 8.3W and a rated voltage from 12V to 24V DC. It is furnished with 6-way removable connector (power supply) for electrical connection Its dimensions are 60mm (width) x 145mm (height) x 125mm (depth) and weighs 0.61 kg. It has shielded connectors which are suitable for medium, isolated networks or system with medium network traffic and network with medium complexity levels. It is CE, UL, RCM, DNV certified and conforms to UL 508, EN/IEC 61131 and EN/IEC 60950 standards. It is designed to be mounted on a 35mm symmetrical DIN rail. The Modicon Networking range offers you a smart and flexible way to integrate Ethernet solutions into your operation, from the device level to the control network and to your corporate network.

Manufacturer

Schneider Electric

Part number

TCSEFEC23FCF21

Product family

Modicon

Category

PLCs & Controllers

Technical details

Range: Modicon; Voltage: 12V, 24V DC; Power: 8.3W; Published sizes: 60mm, 145mm, 125mm, 35mm; Material: copper; Official designation: ConneXium Industial Firewall - 1 port for copper + 1 port for fiber optic multimode

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
