SSP3A250B7

Schneider Electric SSP3A250B7: This SSP three-phase solid state relay is part of the range of solid state modular relays Harmony. It features 50A power rating and 3NO contacts. It features a control circuit voltage of 18V to 36V AC and an output voltage (load output) of 48V to 530V AC. This relay is maintenance free, fully electronic with unlimited life span. It features a control input voltage LED indicator in green. Its protection index is IP20. It weighs 240g and its dimensions are, 101.3mm wide, 79.7mm high, 35.4mm deep. It is the ideal solution for packaging, plastic molding, textile, and heating furnace applications. It can be mounted on panel fixed by screws.

Manufacturer

Schneider Electric

Part number

SSP3A250B7

Product family

Harmony Solid State Relays

Category

Relays & Timers

Technical details

Range: Harmony Solid State Relays; Voltage: 18-36 V AC, 48-530 V AC, 18V, 36V AC, 48V; Current: 50A; Published sizes: 101.3mm, 79.7mm, 35.4mm; Ingress protection: IP20; Poles / contacts: 3NO; Colour: green; Material: plastic; Official designation: solid state relay - panel mounting - input 18-36 V AC, output 48-530 V AC, 50A
