NSYSC630

Schneider Electric NSYSC630: Multi-purpose canopy for PanelSeT SM enclosures The canopy is to be installed on all enclosure models with 600mm width and 300mm depth The nominal width is 600mm and real width is 607mm The nominal depth is 300mm and real depth is 325mm The height is 85mm Fixed by screws - roof drilled holes location on top of enclosure The canopy is made from galvanised steel (color RAL 7035) Provides high resistance to impacts, temperature and bad weather Anti-corrosion protection is ensured by epoxy-polyester powder coating The kit is made up of 1 canopy, fixing elements and drilling template This product is qualified as a green premium, with minimal use of hazardous substances.

Manufacturer

Schneider Electric

Part number

NSYSC630

Product family

PanelSeT SF

Category

Enclosures & Accessories

Technical details

Range: PanelSeT SF; Dimensions: 600x300 mm; Published sizes: 600mm, 300mm, 607mm, 325mm, 85mm; Colour: RAL 7035, green; Material: galvanised steel, polyester; Official designation: PanelSet SF/SM canopy - 600x300 mm
