MR-J5-200G

Mitsubishi Electric MR-J5-200G is an AC servo amplifier in the MELSERVO-J5 series. Key characteristics include command interface CC-Link IE TSN, voltage class AC200 V, rated capacity 2 kW, rated output current 11.0 A, main-circuit supply three-phase or single-phase AC200 V to 240 V, 50 Hz/60 Hz, main-circuit rated current 10.5 A, control-circuit supply single-phase AC200 V to 240 V, 50 Hz/60 Hz.

Manufacturer

Mitsubishi Electric

Part number

MR-J5-200G

Product family

MELSERVO-J5 series

Category

Servo Drives & Amplifiers

Technical details

Series: MELSERVO-J5 series; Model: MR-J5-200 g; Command interface: CC-Link IE TSN; Voltage class: AC200 V; Rated capacity: 2 kW; Rated output current: 11.0 A; Main-circuit supply: three-phase or single-phase AC200 V to 240 V, 50 Hz/60 Hz; Main-circuit rated current: 10.5 A; Control-circuit supply: single-phase AC200 V to 240 V, 50 Hz/60 Hz; Control-circuit power: 30; Control method: sine-wave PWM and current control; Dynamic brake: built in; Enclosure / protection: forced-air cooling, open type (IP20); Weight: 2.2 kg

Weight

2.2 kg

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
