MR-J4-15KB

Mitsubishi Electric MR-J4-15KB is an AC servo amplifier in the MELSERVO-J4 series. Key characteristics include command interface SSCNETⅢ/H, voltage class AC200 V, rated capacity 15 kW, rated output voltage three-phase AC170 V, rated output current 87.0 A, main-circuit supply three-phase AC200 V to 240 V, 50 Hz/60 Hz, main-circuit rated current 64.0 A.

Manufacturer

Mitsubishi Electric

Part number

MR-J4-15KB

Product family

MELSERVO-J4 series

Category

Servo Drives & Amplifiers

Technical details

Series: MELSERVO-J4 series; Model: MR-J4-15KB; Command interface: SSCNETⅢ/H; Voltage class: AC200 V; Rated capacity: 15 kW; Rated output voltage: three-phase AC170 V; Rated output current: 87.0 A; Main-circuit supply: three-phase AC200 V to 240 V, 50 Hz/60 Hz; Main-circuit rated current: 64.0 A; Control-circuit supply: single-phase AC200 V to 240 V, 50 Hz/60 Hz; Control-circuit power: 45; Control method: sine-wave PWM and current control; Enclosure / protection: forced-air cooling, open type (IP20); Operating temperature: 0 °C to 55 °C (non-freezing); Weight: 13.4 kg

Weight

13.4 kg
