MR-J3W-44B

Mitsubishi Electric MR-J3W-44B is an AC servo amplifier in the MELSERVO-J3 series. Key characteristics include command interface SSCNETⅢ, voltage class 200V, rated capacity 0.4 kW, rated output voltage three-phase AC170 V, main-circuit supply three-phase AC200 to 230V/50, 60Hz single-phase AC200 to 230V/50, 60Hz, main-circuit rated current 6.1 A, control-circuit supply single-phase AC200 to 230V/50, 60Hz.

Manufacturer

Mitsubishi Electric

Part number

MR-J3W-44B

Product family

MELSERVO-J3 series

Category

Servo Drives & Amplifiers

Technical details

Series: MELSERVO-J3 series; Model: MR-J3 W-44B; Command interface: SSCNETⅢ; Voltage class: 200V; Rated capacity: 0.4 kW; Rated output voltage: three-phase AC170 V; Main-circuit supply: three-phase AC200 to 230V/50, 60Hz single-phase AC200 to 230V/50, 60Hz; Main-circuit rated current: 6.1 A; Control-circuit supply: single-phase AC200 to 230V/50, 60Hz; Control-circuit power: 55; Control method: sine-wave PWM and current control; Dynamic brake: built in; Enclosure / protection: forced-air cooling, open type (IP00); Operating temperature: operation: 0 °C to 55 °C (non-freezing), storage: -20 °C to 65 °C (non-freezing); Weight: 1.4 kg

Weight

1.4 kg

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
