MR-J3-22KB4-RJ004U532

Mitsubishi Electric MR-J3-22KB4-RJ004U532 is an AC servo amplifier in the MELSERVO-J3 series. Key characteristics include command interface SSCNETⅢ, voltage class 400V, rated capacity 22 kW, rated output voltage three-phase AC323V, rated output current 63.0 A, main-circuit supply three-phase AC380 to 480V/50, 60Hz, main-circuit rated current 47.6 A.

Manufacturer

Mitsubishi Electric

Part number

MR-J3-22KB4-RJ004U532

Product family

MELSERVO-J3 series

Category

Servo Drives & Amplifiers

Technical details

Series: MELSERVO-J3 series; Model: MR-J3-22KB4-RJ004U532; Command interface: SSCNETⅢ; Voltage class: 400V; Rated capacity: 22 kW; Rated output voltage: three-phase AC323V; Rated output current: 63.0 A; Main-circuit supply: three-phase AC380 to 480V/50, 60Hz; Main-circuit rated current: 47.6 A; Control-circuit supply: single-phase AC380 to 480V/50, 60Hz; Control-circuit power: 45; Control method: sine-wave PWM and current control; Enclosure / protection: forced-air cooling, open type (IP00); Operating temperature: 0 to 55 °C (non-freezing), storage: -20 to 65 °C (non-freezing); Weight: 19 kg

Weight

19 kg
