6064109

SICK 6064109 / WF80-60B41CB01 is a fork sensor in the WF family. Communication interface: IO-Link; Adjustment: Teach-in button, cable; Light source: LED; Fork width/depth: 80 mm, 59 mm; Switching output: Push-pull: PNP/NPN; Switching mode: Light/dark switching; Connection type Detail: Cable open end; Switching frequency: 15 kHz; Response time: ≤ 46 µs; Enclosure rating: IP65.

Manufacturer

Sick

Part number

6064109

Product family

WF

Category

Fork sensors

Technical details

Minimum detectable object (MDO): 0.2 mm; Supply voltage: 10 V DC... 30 V DC; Switching output: Push-pull: PNP/NPN; Switching output (voltage): Push-pull: PNP/NPN High = UV - < 2 V/Low: ≤ 2 V; Response time: ≤ 46 µs; Stability of response time: ± 20 µs; Dimensions (W x H x D): 10 mm x 110 mm x 74 mm; Connection type: Cable open end, 300 mm; Enclosure rating: IP65; Housing material: Aluminum; Ambient operating temperature: –20 °C... +60 °C; Weight: Approx. 36 g... 160 g; Functional principle: Optical detection principle; Fork width: 80 mm

Weight

0.036 kg

Dimensions

10 x 110 x 74
