6041738

SICK 6041738 / FFUS20-1G1IO is a flow sensor in the FFU family. Nominal width measuring tube: DN 20; Maximum flow: ≤ 60 l/min; Wetted parts: PPSU, EPDM; Process connection: G 1; Output signal: Analog output 4 mA... 20 mA, 0 mA... 20 mA current flow and temperature, 1 pulse/status output PNP/NPN-transistor output for flow rate meter, empty pipe detection, flow monitoring, dosing output, flow direction (dependent on type); Process temperature: 0 °C... +80 °C; Process pressure: ≤ 10 bar.

Manufacturer

Sick

Part number

6041738

Product family

FFU

Category

Flow sensors

Technical details

Resolution: 0.012 l/min; Supply voltage: 18 V DC... 30 V DC; Communication interface: -; Measurement accuracy: ± 2 % of measured value + 0.15% of measuring range limit value; Repeatability: ≤ 0.5 %; Response time: 100 ms; 300 ms; 1 s; 4.2 s; Connection type: Round connector M12 x 1, 5-pin; Enclosure rating: IP67; Housing material: PPSU; Ambient operating temperature: 0 °C... +60 °C; Weight: 420 g; Measurement principle: Ultrasonic sensor; Medium: Fluids; Nominal width measuring tube: DN 20

Weight

0.42 kg
