6029527

SICK 6029527 / WLL170-2P162 is an archive in the WLL170 family. Fiber-optic sensors; Sensing range max.: 1... 2 m; Input: -; Number of switching outputs: 1; Switching mode: Light/dark switching; Connection type: Cable, 3-wire; Enclosure rating: IP66; Adjustment: Potentiometer.

Manufacturer

Sick

Part number

6029527

Product family

WLL170

Category

Archive

Technical details

Type of light: Visible red light; Sensing range max.: 0 mm... 1,600 mm (Through-beam system); Sensing range: 0 mm... 65 mm, Proximity system; 0 mm... 350 mm, Through-beam system; Supply voltage UB: 10 V DC... 30 V DC; Switching output: PNP; Number of switching outputs: 1; Response time: ≤ 50 µs; Dimensions (W x H x D): 10.5 mm x 35.5 mm x 83.7 mm; Connection type: Cable, 3-wire, 2 m; Enclosure rating: IP66; Housing material: Plastic, ABS/PC; Ambient operating temperature: –25 °C... +55 °C; Weight: 70 g; Device type: Fiber-optic amplifier

Weight

0.07 kg

Dimensions

10.5 x 35.5 x 83.7
