6008785

SICK 6008785 / VL180-P460 is an archive in the V180 family. Photoelectric sensors; Functional principle: Photoelectric retro-reflective sensor; Switching output: PNP; Switching mode: Light/dark switching; Connection type: Male connector M12, 4-pin; Light source: LED; Adjustment: None; Communication interface: -; Included with delivery: Reflector P250, fastening nuts (2 x).

Manufacturer

Sick

Part number

6008785

Product family

V180

Category

Archive

Technical details

Type of light: Visible red light; Sensing range max.: 0.05 m... 1 m; Sensing range: 0.05 m... 1 m; Supply voltage UB: 10 V DC... 30 V DC; Switching output: PNP; Response time: ≤ 1.5 ms; Dimensions (W x H x D): 18 mm x 18 mm x 69 mm; Connection type: Male connector M12, 4-pin; Enclosure rating: IP66; Housing material: Metal, Nickel-plated brass, PBT/PC; Ambient operating temperature: –25 °C... +55 °C; Weight: 65 g; Functional principle: Photoelectric retro-reflective sensor; Housing design (light emission): Cylindrical

Weight

0.065 kg

Dimensions

18 x 18 x 69

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
