1221947

SICK 1221947 / RAY26P-34162530A00 is a photoelectric sensor in the RAY26 Reflex Array family. Minimum object size: 5 mm; Detection height: 55 mm; Sensing range max.: 0 m... 3 m; Functional principle: Photoelectric retro-reflective sensor; Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics), Reflex Array; Switching output: Push-pull: PNP/NPN; Switching mode: Light/dark switching; Connection type: Cable with M12 male connector, 4-pin, 270 mm; Light source: PinPoint LED; Adjustment: Teach-in button, IO-Link; Communication interface: IO-Link.

Manufacturer

Sick

Part number

1221947

Product family

RAY26 Reflex Array

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0 m... 3 m; Detection height: 55 mm; Supply voltage UB: 10 V DC... 30 V DC; Switching output: Push-pull: PNP/NPN; Response time: ≤ 3 ms; Repeatability: SIO Direct: 1,5 ms; SIO Logic: 1,5 ms; IOL: 1,5 ms; Dimensions (W x H x D): 24.6 mm x 82.5 mm x 53.3 mm; Connection type: Cable with M12 male connector, 4-pin, 270 mm; Enclosure rating: IP66; IP67; Housing material: Plastic, VISTAL®; Ambient operating temperature: –40 °C... +60 °C; Weight: 100 g; Functional principle: Photoelectric retro-reflective sensor

Weight

0.1 kg

Dimensions

24.6 x 82.5 x 53.3
