1204680

SICK 1204680 / M40E-64A323RB0 is an archive in the M4000 Advanced Curtain family. Safety light curtains; System part: Receiver; Resolution: 30 mm; Scanning range: 21 m; Protective field height: 900 mm; Connection type: Hirschmann male connector M26, 12-pin; Extension connection: Female connector M12, 5-pin; Configuration method: Via software; End cap with integrated LED on the receiver: yes.

Manufacturer

Sick

Part number

1204680

Product family

M4000 Advanced Curtain

Category

Archive

Technical details

Resolution: 30 mm; Supply voltage VS: 24 V DC (19.2 V... 28.8 V); Safe SICK device communication via EFI: ✔; Response time: Without beam coding 12 ms; Enclosure rating: IP65 (EN 60529); Housing material: Aluminum alloy ALMGSI 0.5; Ambient operating temperature: –30 °C... +55 °C; System part: Receiver; Scanning range: 21 m; Protective field height: 900 mm; With beam coding: 18 ms; Synchronization: Optical synchronization; Type: Type 4 (IEC 61496-1); Safety integrity level: SIL 3 (IEC 61508)

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
