1124859

SICK 1124859 / WTB26I-24G11420ZZZ is a photoelectric sensor in the W26 family. Sensing range min. / max.: 30 mm / 3,000 mm; Functional principle: Photoelectric proximity sensor; Functional principle detail: Background suppression; Switching output: NPN; Switching mode: Light/dark switching; Connection type: Male connector M12, 4-pin; Light source: LED; Type of light: Infrared light; Housing material: VISTAL®; Adjustment: Teach-in button, Wire/pin, Potentiometer, Teach-Turn adjustment; Housing: Rectangular.

Manufacturer

Sick

Part number

1124859

Product family

W26

Category

Photoelectric sensors

Technical details

Type of light: Infrared light; Sensing range: Sensing range min. 30 mm; Sensing range max.: 3,000 mm; Minimum distance between set sensing range and background (black 6% / white 90%): 190 mm, at a distance of 1000 mm; Recommended sensing range for the best performance: 200 mm... 1,000 mm; Supply voltage UB: 10 V DC... 30 V DC; Overcurrent and short-circuit protected Response time: ≤ 2.5 ms; Repeatability (response time): 150 µs; Dimensions (W x H x D): 20 mm x 55.7 mm x 42 mm; Enclosure rating: IP66 (EN 60529); IP67 (EN 60529); IP69 (EN 60529); Ambient operating temperature: –40 °C... +60 °C; Weight: Approx. 80 g; Functional principle: Photoelectric proximity sensor; Functional principle detail: Background suppression

Weight

0.08 kg

Dimensions

20 x 55.7 x 42
