1100798

SICK 1100798 / WLA26P-P03 is an archive in the W26 family. Photoelectric sensors; Sensing range min. / max.: 0 m / 18 m; Functional principle: Photoelectric retro-reflective sensor; Functional principle detail: Without reflector minimum distance (autocollimation/coaxial optics); Switching output: Push-pull: PNP/NPN; Switching mode: Light/dark switching; Connection type: Male connector M12, 4-pin; Light source: PinPoint LED; Type of light: Visible red light; Housing material: VISTAL®; Adjustment: IO-Link; Communication interface: IO-Link V1.1; Smart Sensor: Enhanced Sensing, efficient communication, diagnosis, Smart Task; Smart Task name: Base logics; Special features: With BEF-WN-W23, 2019085 and PL40A, 1012720; Housing: Rectangular; Included with delivery: BEF-WN-W23 mounting bracket and PL40A reflector.

Manufacturer

Sick

Part number

1100798

Product family

W26

Category

Archive

Technical details

Type of light: Visible red light; Sensing range: Sensing range min. 0 m; Sensing range max.: 18 m; Recommended sensing range for the best performance: 0 m... 12 m; Supply voltage UB: 10 V DC... 30 V DC; Overcurrent and short-circuit protected Response time: ≤ 500 µs; Repeatability (response time): 150 µs; Response time: SIO Logic: 600 µs; IOL: 750 µs; Repeatability: SIO Logic: 300 µs; IOL: 400 µs; Dimensions (W x H x D): 24.6 mm x 82.5 mm x 53.3 mm; Enclosure rating: IP66 (EN 60529); IP67 (EN 60529); IP69 (EN 60529); Ambient operating temperature: –40 °C... +60 °C; Weight: Approx. 80 g; Functional principle: Photoelectric retro-reflective sensor

Weight

0.08 kg

Dimensions

24.6 x 82.5 x 53.3

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
