1096101

SICK 1096101 / RAY10-AB5EBLA00 is a photoelectric sensor in the RAY10 Reflex Array family. Minimum object size: 5 mm; Detection height: 25 mm; Sensing range max.: 0 m... 1.5 m; Functional principle: Photoelectric retro-reflective sensor; Functional principle detail: With minimum distance to reflector (dual lens system), Reflex Array; Switching output: Push-pull: PNP/NPN; Switching mode: Light/dark switching; Connection type: Cable with male connector M8, 4-pin, snap, 1 m; Light source: PinPoint LED; Adjustment: Potentiometer, IO-Link; Communication interface: IO-Link.

Manufacturer

Sick

Part number

1096101

Product family

RAY10 Reflex Array

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0 m... 1.5 m; Detection height: 25 mm; Supply voltage UB: 10 V DC... 30 V DC; Switching output: Push-pull: PNP/NPN; Response time: ≤ 0.5 ms; Repeatability: SIO Direct: 1 ms; SIO Logic: 1 ms; IOL: 2,3 ms; Dimensions (W x H x D): 21.5 mm x 36 mm x 37.7 mm; Connection type: Cable with male connector M8, 4-pin, snap, 1 m; Enclosure rating: IP67; Housing material: Plastic, ABS; Ambient operating temperature: –40 °C... +60 °C; Weight: 130 g; Functional principle: Photoelectric retro-reflective sensor

Weight

0.13 kg

Dimensions

21.5 x 36 x 37.7
