1095448

SICK 1095448 / GSE2F-P5151 is a photoelectric sensor in the G2 family. Functional principle: Through-beam photoelectric sensor; Switching output: PNP; Switching mode: Light switching; Connection type: Cable with connector M8, 3-pin, 200 mm; Light source: PinPoint LED; Adjustment: None; Communication interface: -.

Manufacturer

Sick

Part number

1095448

Product family

G2

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0 mm... 700 mm; Sensing range: 0 m... 500 mm; Minimum detectable object (MDO): 1 mm; Supply voltage UB: 10 V DC... 30 V DC; Switching output: PNP; Response time: < 0.625 ms; Repeatability (Ta not constant): 0.1 mm; Dimensions (W x H x D): 10 mm x 27 mm x 3.5 mm; Connection type: Cable with connector M8, 3-pin, 200 mm; Enclosure rating: IP67; Housing material: Plastic, VISTAL®; Ambient operating temperature: –20 °C... +50 °C; Weight: 23 g

Weight

0.023 kg

Dimensions

10 x 27 x 3.5
