1091946

SICK 1091946 / IME2S12-04N4DC0 is a safety switche in the IME2S family. Design: Cylindrical; Sensing range Sn: 4 mm; Dimensions: M12 x 65 mm; Thread length: 36.9 mm; Installation type: Non-flush; Connection type Detail: Male connector M12, 4-pin; Type of output: Self-monitoring semiconductor outputs (OSSDs); Performance level: PL d.

Manufacturer

Sick

Part number

1091946

Product family

IME2S

Category

Safety switches

Technical details

Sensor principle: Inductive; Sensing range Sn: 4 mm; Supply voltage Vs: 24 V DC (19.2 V DC... 28.8 V DC); Response time: ≤ 1 ms; Connection type: Male connector M12, 4-pin; Enclosure rating: IP67 (IEC 60529); Ambient operating temperature: –25 °C... +70 °C; Number of safe outputs: 2; Housing diameter: M12; Assured switch on distance Sao: 3.2 mm; Assured switch off distance Sar: 6 mm; Active sensor surfaces: 1; Actuation frequency: ≤ 100 Hz; Items supplied: Including mounting nuts, brass, nickel-plated (2x)
