1077629

SICK 1077629 / HL18-L5B3AA is a photoelectric sensor in the H18 Sure Sense family. Device version: Standard; Communication interface: -; Mounting system type: M18, head/side (24.1 … 25.4 mm); Sensor/ detection principle: Photoelectric retro-reflective sensor, With minimum distance to reflector (dual lens system); Sensing range: 6.5 m; Light source, light type: PinPoint LED, visible red light; Voltage type: AC/DC; Switching output Q1: MOSFET, Light switching; Potentiometer, right: None; Potentiometer, left: None; Connection type: Cable with male connector, micro (1/2”-20), 4-pin, 150 mm.

Manufacturer

Sick

Part number

1077629

Product family

H18 Sure Sense

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0.03 m... 6.5 m; Sensing range: 0.03 m... 5 m; Supply voltage: 21.6 V DC... 250 V DC, 96 V AC... 250 V AC; Switching output: MOSFET; Switching output detail: Switching output Q1 MOSFET, Light switching; Response time: ≤ 0.5 ms; Dimensions (W x H x D): 16.2 mm x 45.5 mm x 34.4 mm; Connection type: Cable with male connector, micro (1/2”-20), 4-pin, 150 mm; Connection type Detail: Cable material Plastic; Enclosure rating: IP67; IP69K; Housing material: Plastic, VISTAL®; Ambient operating temperature: –40 °C... +70 °C; Weight: 18 g

Weight

0.018 kg

Dimensions

16.2 x 45.5 x 34.4
