1073433

SICK 1073433 / HTB18-P3A2BB is a photoelectric sensor in the H18 Sure Sense family. Device version: Standard; Communication interface: -; Mounting system type: M18, head/side (24.1 … 25.4 mm); Sensor/ detection principle: Photoelectric proximity sensor, Background suppression; Sensing range: 300 mm; Light source, light type: PinPoint LED, visible red light; Voltage type: DC; Switching output Q1: PNP, Light switching; Switching output Q2: PNP, Dark switching; Potentiometer, right: Sensing range; Potentiometer, left: None; Connection type: Male connector M8, 4-pin.

Manufacturer

Sick

Part number

1073433

Product family

H18 Sure Sense

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 5 mm... 300 mm; Sensing range: 5 mm... 150 mm; Supply voltage: 10 V DC... 30 V DC; Switching output: PNP; Switching output detail: Switching output Q1 PNP, Light switching; Switching output Q2: PNP, Dark switching; Response time: ≤ 0.5 ms; Dimensions (W x H x D): 16.2 mm x 44.9 mm x 31.8 mm; Connection type: Male connector M8, 4-pin; Connection type Detail: Cable material Plastic; Enclosure rating: IP67; IP69K; Housing material: Plastic, VISTAL®; Ambient operating temperature: –40 °C... +65 °C

Weight

0.018 kg

Dimensions

16.2 x 44.9 x 31.8

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
