1062539

SICK 1062539 / RE13-SA84 is a safety switche in the RE1 family. Systemteil: Sensor with actuator; N/O contacts: 2; N/C contacts: 0; Signaling contacts: 0; Connection type Detail: Cable with M8 male connector, 4-pin; Length of cable: 0.2 m; Safe series connection: None, only individual wiring (with diagnostics); Status display: no.

Manufacturer

Sick

Part number

1062539

Product family

RE1

Category

Safety switches

Technical details

Sensor principle: Magnetic; Dimensions (W x H x D): 26 mm x 36 mm x 13 mm; Connection type: Cable with M8 male connector, 4-pin; Enclosure rating: IP67 (IEC 60529); Housing material: VISTAL®; Ambient operating temperature: –30 °C... +60 °C; Weight: 0.1 kg; System part: Sensor with actuator; N/O contacts: 2; N/C contacts: 0; Signaling contacts: 0; Assured switch on distance Sao: 7 mm; Assured switch off distance Sar: 20 mm; Active sensor surfaces: 1

Weight

0.1 kg

Dimensions

26 x 36 x 13

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
