1062523

SICK 1062523 / WTB9L-3N2261 is a photoelectric sensor in the W9 family. Functional principle: Photoelectric proximity sensor; Functional principle detail: Background suppression; Switching output: NPN; Switching mode: Light/dark switching; Connection type: Male connector M8, 4-pin; Light source: Laser; Adjustment: Potentiometer; Laser class: 1; Communication interface: -.

Manufacturer

Sick

Part number

1062523

Product family

W9

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 25 mm... 300 mm; Sensing range: 25 mm... 300 mm; Supply voltage UB: 10 V DC... 30 V DC; Switching output: NPN; Response time: ≤ 0.5 ms; Dimensions (W x H x D): 12.2 mm x 49.8 mm x 23.6 mm; Connection type: Male connector M8, 4-pin; Enclosure rating: IP66; IP67; IP69K; Housing material: Plastic, VISTAL®; Ambient operating temperature: –10 °C... +50 °C; Ambient operating temperature extended: –30 °C... +55 °C; Weight: 13 g; Functional principle: Photoelectric proximity sensor

Weight

0.013 kg

Dimensions

12.2 x 49.8 x 23.6
