1058182

SICK 1058182 / WSE9L-3P2237 is a photoelectric sensor in the W9 family. Functional principle: Through-beam photoelectric sensor; Switching output: PNP; Switching mode: Light/dark switching; Connection type: Male connector M8, 4-pin; Light source: Laser; Adjustment: Teach-in button; Laser class: 1; Communication interface: -.

Manufacturer

Sick

Part number

1058182

Product family

W9

Category

Photoelectric sensors

Technical details

Type of light: Visible red light; Sensing range max.: 0 m... 60 m; Sensing range: 0 m... 50 m; Supply voltage UB: 10 V DC... 30 V DC; Switching output: PNP; Response time: ≤ 0.5 ms; Dimensions (W x H x D): 12.2 mm x 49.8 mm x 23.6 mm; Connection type: Male connector M8, 4-pin; Enclosure rating: IP66; IP67; IP69K; Housing material: Plastic, VISTAL®; Ambient operating temperature: –10 °C... +50 °C; Ambient operating temperature extended: –30 °C... +55 °C; Weight: 13 g; Functional principle: Through-beam photoelectric sensor

Weight

0.013 kg

Dimensions

12.2 x 49.8 x 23.6

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
