1057657

SICK 1057657 / DL35-B15552 is a laser distance sensor in the Dx35 family. Communication interface: IO-Link; Measuring range: 200 mm... 35,000 mm, on “diamond grade” reflective tape; Laser class: 1; Light source: Laser, red; Minimum response time: 2.5 ms; Digital output: 1... 2 x push-pull: PNP/NPN; Type of analog output: Current output / voltage output; Multifunctional input (MF): 1 x.

Manufacturer

Sick

Part number

1057657

Product family

Dx35

Category

Laser distance sensors

Technical details

Type of light: Visible red light; Resolution: 100 µm; Supply voltage UB: DC 12 V... 30 V; Repeatability: ≥ 0.5 mm; Measurement accuracy: Typ. ± 15 mm; Response time: 2.5 ms... 96.5 ms, 2.5 ms / 6.5 ms / 12.5 ms / 24.5 ms / 96.5 ms; Dimensions (W x H x D): 32 mm x 58.67 mm x 42.7 mm; Connection type: Male connector, M12, 5-pin; Enclosure rating: IP65; IP67; Housing material: Plastic (ABS/PC); Weight: 65 g; Measuring range: 200 mm... 35,000 mm, on “diamond grade” reflective tape; Target: Reflector; Switching frequency: 333 Hz / 100 Hz / 50 Hz / 25 Hz / 6 Hz

Weight

0.065 kg

Dimensions

32 x 58.67 x 42.7
