1047046

SICK 1047046 / LUT8U-11321 is a luminescence sensor in the LUT8 family. Light source: LED; Communication interface: -; Sensing distance: 50 mm; Switching output: PNP, NPN; Switching mode: Light switching; Light spot size: 5 mm x 15 mm; Light spot direction: Vertical; Light emission: Long side; Connection type Detail: Plug, M12, 5-pin.

Manufacturer

Sick

Part number

1047046

Product family

LUT8

Category

Luminescence sensors

Technical details

Working range: 20 mm... 70 mm; Supply voltage: 12 V DC... 30 V DC; Switching output: PNP; NPN; Switching output (voltage): PNP: HIGH = VS– ≤ 3 V / LOW = approx. 0 V; NPN: HIGH = approx. UV / LOW ≤ 2 V; Response time: 200 µs; Dimensions (W x H x D): 30.4 mm x 53 mm x 80 mm; Connection type: Plug, M12, 5-pin; Enclosure rating: IP67; Housing material: Zinc diecast; Ambient operating temperature: –10 °C... +55 °C; Weight: 400 g; Housing design: Large; Light source: LED, Ultraviolet light; Light emission: Long side

Weight

0.4 kg

Dimensions

30.4 x 53 x 80

All New and Used products supplied by NeoIPS include a 12-month warranty as standard. Longer coverage may apply when provided by the manufacturer and will be stated in the quotation or order confirmation.
