1023491

SICK 1023491 / C41E-1001BG300 is an archive in the C4000 Micro family. Safety light curtains; System part: Receiver; Usage: As a standalone system; Safety level: PL e, SIL 3, Type 4; Resolution: 14 mm; Scanning range: 5 m; Protective field height: 1,050 mm; Connection type: Male connector M12, 8-pin; Enclosure rating: IP65.

Manufacturer

Sick

Part number

1023491

Product family

C4000 Micro

Category

Archive

Technical details

Resolution: 14 mm; Supply voltage VS: 24 V DC (19.2 V... 28.8 V); Dimensions: See dimensional drawing; Enclosure rating: IP65 (IEC 60529); Housing material: Aluminum extruded profile; Ambient operating temperature: –30 °C... +55 °C; Weight: 1,100 g; System part: Receiver; Scanning range: 5 m; Protective field height: 1,050 mm; Synchronization: Optical synchronization; Type: Type 4 (IEC 61496-1); Safety integrity level: SIL 3 (IEC 61508); Category: Category 4 (EN ISO 13849)

Weight

0.0011 kg
